OSFP-400G-DR4 400G OSFP DR4 PAM4 1310nm MTP/MPO-12 500m SMF FEC Optical Transceiver Module
OSFP-400G-DR4 400G OSFP DR4 PAM4 1310nm MTP/MPO-12 500m SMF FEC Optical Transceiver Module
Couldn't load pickup availability
400G DR4 OSFP PAM4 Optical Transceiver Module (1310nm MTP/MPO-12 500m SMF with FEC DDM)
Product Details
| P/N | OSFP-400G-DR4 | Vendor Name | DFTTELECOM |
| Form Factor | OSFP | Max Data Rate | 425Gbps |
| Wave length | 1310nm | Max Distance | 500m |
| Connector | MTP/MPO-12 | Voltage Supply | 3.3V |
| Cable Type | SMF | DDM Support | Yes |
| Transmitter Type | 1310nm EML | Receiver Type | PIN |
| TX Power | -2.9~+4.0dBm | ReceiverSensitivity | < -7.3dBm |
| Operation Temperature Protocols |
0 to 70°C (32 to 158°F) | Maximum Power | < 12.0W |
| Application | 400G Ethernet, | ||
| OSFP MSA, IEEE 802.3bs | Datacenter Enterprise Networking, Infiniband Interconnects |
2x400G to 400G Links
400GIB/EN Switches to 2 Connectx-7 and BIueField-3
Quality Assurance
Excellent quality is the foundation of FiberMall' s survival and development. Our operation team are experts with many years' experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.
Quality Certification
We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.
Our Advantages
Rigorous Industrial ProductTesting
Optical communication products belong to industrial products,which require high stability and reliability,DFTTELECOM adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliabl
100% 3rd Party Compatible
DFTTELECOM Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
