DF-RF101-A1 RFID label LED light Data Center Cable Management

1. Product Overview

The DF-RF101-A1 is a RFID labelcompliant with EPC Global Class1 Gen2 V2.0.1 and ISO/IEC 18000-63(Type C), designed for intelligent cable management in data centers.  Its integrated trigger-activated LED enables instant visual identification and precis tracking.

2. Key Features

LED Indication

Activation range ≥1.5m with high-brightness red LED

Reduces manual search time by 90% through instant localization

Data Capacity

128-bit EPC + 96-bit TID + 512-bit USER memory

Stores cable ID, installation details, maintenance logs, etc.

Physical Specifications

Dimensions: 100mm/50mm × 10mm (two options)

Material: White coated paper composite, bend-resistant

Installation: Adhesive backing for cables with OD≤7mm

 System Compatibility

Works with DFT  software (Windows/Android/iOS)

Compatible with handheld/fixed readers (e.g.DF-RF50U)

 Size : 100*10*0.2MM     50*6*0.2mm   Material ( Coated paper , Plastic, PET)

3. Applications

Patch Cord Management: Track A/B-end connectivity in real time

Asset Auditing: Batch scan and export to Excel (registration/inspection records)

Remote Maintenance: Query label data via mobile APP

 4. Technical Specifications

5. Integrated Solution

Hardware: Handheld terminal , Rackmount reader

Software:  for ID registration, patching statistics, and data export

Provide SDK for customer to customize their own applications.
